Description
VIDEO | https://www.youtube.com/watch?v=G2OX6KbqeVA#t=37 |
Machine No. | 1037 |
Cutting width | max310 mm |
Chain width | 340 mm with spikes, every 3rd chain link |
Motor | 37 kW |
Operation voltage | 400V/50Hz |
Feed spped | 5 – 35 m/min |
Saw blade diameter | min./max300/350 mm |
Saw blade bore | 80 mm |
Revolutions of saw arbor | 4200 r/min |
“Quickfix”- system | Hydro quick clamping system for the saw bladesmin. Strip width25 mm |
Cutting height with Quickfix | 110 mm |
Cutting height with saw bushing | 115 mm |
Shortest piece possible | 500 mm |
1 Laser | 20mW |
Air volume for dust exhaust | 5300 m³/h |
Working height | 850 mm |
Total length | 1750 mm |
Total width | 1750 mm |
Height | 1500 mm |
Weight | 2000 kg |
Location | D-32683 Barntrup |
COMMENTS
(Subject to errors, technical modifications and prior sale)
