ShopYou are here: Home / English / Sold / Heavy – Duty Circular Edgers Ripsaw, PAUL KME 2/750, Year 2007 Heavy – Duty Circular Edgers Ripsaw, PAUL KME 2/750, Year 2007
Description
fully hydraulic | |
Height adjustment of upper rollers and climbing Saegeblattverstellung hydraulically | |
Cutting height | 125 mm |
Passage width | 750 mm |
Blade – max diameter | 380 mm |
Shortest cutting length | 600 mm |
Diameter main shaft | 60 mm |
5 driven rollers | |
Upper roll diamete | r 252 mm |
Hydraulic feed infinitely variable | 2-75 m / min |
Engine | 22 kW |
Saw spindle speed | 2900 rev / min |
1cm and 2cm blade adjustment with detent including 1 mobile standard 110mm saw box and saw 1 box with fixed 60 mm Usable spun len | |
Remote control for 4 5 m table length | |
Hydraulic adjustable rip fence | 2500 mm Manuel |
Adjustment | 300 mm |
grow right | |
Roller table | wood input side with 7 rollers 4400 mm / 715 mm |
Universalausfuehrung roll width | 574 mm, screw-on machine |
Weight about | 1850 kg with wheels |
Location | D-32683 Barntrup |
